Description
Product Highlights:
- Auto Power Adjustments – By default, the Auto Output Power option allows the LTU LR to set the output power (EIRP) to the appropriate level.
- Signal Control – The LTU LR’s TX output power is controlled by the AP’s target TX output power. A PtMP network can manage signal levels to enhance network stability and achieve optimal wireless performance with the highest possible modulation.
- Convenient Configuration – To manage the LTU LR, you have two options: the LTU Configuration Interface and Ubiquiti Network Management System (UNMS™). Either option lets you manually configure the LTU LR.
Technical details:
- Dimensions : 512.5 x 385.75 x 258.3 mm (20.18 x 15.19 x 10.17″)
- Weight With Mount : 360 kg (2.998 lb) 735 kg (3.825 lb)
- Networking Interface : (1) 10/100/1000 Ethernet Port
- Enclosure Outdoor : UV Stabilized Plastic
- Power Consumption : 8.5W
- Power Supply : 24V, 0.5A Gigabit PoE Adapter (Included)
- Power Method : 24V Passive PoE (Pairs 4, 5+; 7, 8-)
- Voltage Range : 22 – 26V
- Conducted : TX Power 22 dBm (per Chain) Gain 26 dBi
- Mounting Pole-Mount (Kit Included)
- Wind Loading : 550 N @ 200 km/h (123.6 lbf @ 125 mph)
- Wind Survivability : 200 km/h (125 mph)
- ESD/EMP Protection : ± 24kV Contact/Air
- Operating Temperature : -40 to 60° C (-40 to 140° F)
- Operating Humidity : 5 to 95% Noncondensing
- Certifications : CE, FCC, IC
Product key features:
- PtMP CPE
- 1024 QAM
- 10/20/30/40/50 MHz channel bandwidth
- Central configuration management from AP side
- Frequency split
- Auto power adjustments
- Router mode support
- Range up to 30km
- Functions in a PtMP environment with the LTU-Rocket as the basestation
