Description
Product introduction:
Featuring a powerful internal antenna, the LTU Lite 5 GHz PtMP Subscriber Station & Client Radio from Ubiquiti Networks is a Customer Premises Equipment (CPE) device that’s built to work in a Point-to-MultiPoint (PtMP) environment with the LTU Rocket as the BaseStation. It uses Ubiquiti’s proprietary LTU technology to provide fast and reliable 802.11 Wi-Fi connections that can transfer over 600 Mb/s over the 5 GHz signal band. The LTU Lite supports both bridged and built-in NAT router modes to suit your deployment. You can also individually configure the TX and RX frequencies to avoid local interference. Made from UV stabilized plastic, the LTU Lite may be installed outdoors using the included wall and pole mounts, connecting to the client’s switch or router through its Gigabit Ethernet port with the included PoE injector placed in between to provide power.
Product Highlights:
- Reliable Connectivity – The LTU Lite PtMP CPE features a powerful internal 13 dBi antenna that delivers reliable 802.11 Wi-Fi connections to LTU Rocket BaseStations.
- LTU Technology – Ubiquiti’s LTU technology is designed to overcome the limitations of the 802.11 Wi-Fi standard by using a custom processor and radio architecture to deliver over 600 Mb/s throughput and modulation rates of up to 4096 QAM.
- Independent TX & RX Configurations – The TX and RX channels may be individually configured to the 10, 20, 30, 40, and 50 MHz frequencies to avoid interference.
- Signal Control – The LTU Lite’s target TX output power controls each station’s TX output power. A PtMP network can manage signal levels to enhance network stability and wireless performance with the highest possible modulation.
- Auto Power Adjustments – The Auto Output Power option allows the LTU Lite to set the output power (EIRP) to the appropriate level.
- Convenient Mounting Options – Quickly mount the LTU Lite onto a pole or wall using the included kits.
Product key features:
- For LTU Rocket BaseStation
- Point-to-MultiPoint (PtMP) Device
- Customer Premises Equipment (CPE)
- Supports 802.11 Wi-Fi
- 5 GHz (Single-Band)
- 1 x 13 dBi Internal Antenna
- 1 x PoE-Compliant Gigabit Ethernet Port
- LTU Technology
- Includes PoE Injector
- Outdoor Pole & Wall Mount Kits Included.
